Description
The cocoa powder grinding machine is a fine pulverizing equipment, and the particle size of the cocoa powder can reach 100 meshes. The whole machine is 201 stainless steel. This machine needs to be used in combination with a cocoa bean grinder and a cocoa butter press for processing cocoa powder.
Cocoa Powder Production Process:
Cocoa Bean – Roasting – Peeling – Grinding sauce – Pressing oil – Crushing cocoa cake – Fine grinding – Cocoa powder
The cocoa cake after oil extraction is thick and firm, so it is necessary to use the crushing equipment for coarse crushing, and then use the machine for fine grinding.
Working Principle of Cocoa Powder Grinding Machine:
The pendulum design is adopted, and the speed can reach 3800r/min. The material is smashed after multiple shearing in the pendulum. Finally, the cocoa powder with uniform particles is formed through an adjustable mesh screen.
Advantages of Cocoa Powder Making Machine for Sale
- The machine is made of 201 stainless steel, and the inner wall of the casing is all machined to achieve a smooth surface.
- The crushing effect is good, and the materials are crushed under the combined effects of impact, friction, shearing, and the impact between materials.
- The mesh of the finished product can be changed by replacing the screen with a different fineness.
- The structure is simple, sturdy, and stable in operation.
- This machine is suitable for crushing various dry and brittle materials, such as pepper, ginger powder, garlic powder, leaf powder, etc.
Parameter of Cocoa Powder Grinding Machine
| Model | LG-S20B | LG-S30B | LG-S40B |
| Capacity(kg/h) | 50-100 | 50-200 | 100-400 |
| Crushed powder fineness(mesh) | 20-120 | 20-120 | 20-120 |
| Cutter diameter(mm) | 200 | 300 | 350 |
| Host power(kw) | 4 | 5.5 | 11 |
| Dimension(mm) | 600*500*1170 | 750*600*1370 | 850*700*1450 |
| Weight(kg) | 140 | 220 | 440 |
