Description
This cocoa cake crusher machine is specially designed for coarse crushing of various hard materials, with high grinding efficiency and adjustable granularity of the finished product.
In the process of making cocoa powder, after coarsely crushing, a fine grinder is needed to obtain cocoa powder with higher fineness.
Features of Cocoa Cake Grinding Machine
- Special machinery for cocoa cake crushing, with low operating noise.
- The granularity of the finished product is adjustable.
- The parts in contact with food are made of stainless steel, which is in line with food production safety.
- The size of the special material gate device and the screen mesh can be designed. To meet the requirements of various material shapes and particle sizes.
- There is a dust-proof movable trolley at the bottom to facilitate the transfer of materials.
Working Principle of Cocoa Cake Crushing Machine:
In the revolving movement, the claw-shaped knife on the movable cutter head and the fixed knife on the static knife holder make a cutting movement, thereby crushing the material.
This machine is very suitable for crushing soft and elastic materials, such as bones, oil cakes, spices, etc.
The coarsely crushed cocoa cake has a large particle size, so further crushing is required. You need a cocoa powder grinding machine. The particle size of cocoa powder produced by this machine can reach 100 meshes.
Parameter of Cocoa Cake Crusher Machine Stainless Steel
| Model | Capacity(kg/h) | Smash caliber(mm) | Power(kw) | Dimension(mm) | Weight(kg) |
| LG-PG300 | 80-200 | 300*210 | 5.5 | 1000*700*1260 | 290 |
| LG-PG400 | 150-400 | 380*250 | 7.5 | 1080*820*1330 | 520 |
| LG-PG500 | 200-600 | 500*250 | 11 | 1700*1350*1760 | 900 |
Instructions for Use of Cocoa Cake Pulverizer:
- After starting the machine, let it idle for 3 minutes. Fasten the feeding room so that the protection switch is in full contact. It can be put into production if it meets the crushing conditions.
- It is forbidden to put iron and other hard objects into the crushing chamber.
- If abnormal sound is found, stop the machine immediately, check the cause, and restart the machine after troubleshooting.
